Prosense ATEX/IECEx certified "P" Series fixed gas detectors are designed and developed according to the demanding conditions found in industrial plants in order to carry out continuous measurement of toxic, explosive and oxygen gases in the air.
Pellistor, Electrochemical, and Infrared sensors employed P Series detectors show excellent outputs in LEL, ppm, VOL ranges
Ask the Expert
Connectivity
• Wide Range Sensors: Pellistor, Electrochemical, Infrared, Semiconductor employed P provides excellent output for the target gas.
• Modbus: P can be integrated to SCADA systems easily via open source Modbus RS485(RTU) codes
• Outputs: Different devices can be operated/controlled at the same time thanks to the 4-20mA analog, Modbus RS485 and Relay outputs
• Relay Contacts: P-3R+ relay module integrated P Series detectors can manage other equipments or link to firefighting panels.
Maintenance and Installation
• Sensor Replacement: Allows sensor replacement with pre-calibrated sensor head to provide easy maintenance.
• Installation: Designed for either wall or ceiling mounting applications
• Entry: 2 x 1/2″ NPT cable entries
• Remote Control: Detector status can be monitored Prosense Gas Monitoring software remotely.
Robust and Reliable
• Body: Aluminium die-cast body and SS316 stainless steel sensor head superb performance under harsh environmental conditions with IP65 protection class.
• Protection: Sunshield and waterproof caps are available for use in extreme conditions.
| Sensor Technology | Pellistor, Electrochemical, Infrared, Semiconductor |
| Output Signal | 4-20mA and Modbus RS485 |
| Sensor Warm-Up | 60sec |
| Response Time(T90) | Sensor dependent |
| Accuracy | %1 |
| Operating Temperature | -40°C ~ +70°C |
| Humidity | 5 ~ 95%RH |
| Input | Min 10VDC - Max 32VDC - Nominal 24VDC |
| Power Consumption | Max. 4W |
| Relay Outputs | 2 Alarms (Selectable) and 1 Fault (All relays are NO/NC adjustable) |
| IP Rating | IP65 / Optional IP66 (Sensor Head) |
| Junction Box | Epoxy Painted Die-Cast Aluminum |
| Sensor Head | 316L Stainless Steel |
| Dimensions/Weight | 183x118,15x88mm / 1420gr |
| ATEX Marking | II 2G Ex db IIC T5/T4 Gb |
| Hazardous Class | Zone 1 or Zone 2 |
| Certificates | IMQ 19 ATEX 045 X IECEx IMQ 18.0009X |
| Standards | IEC EN 60079-0 IEC EN 60079-1 IEC EN 60079-18 |
| P-3R+ | Provides 2xAlarms, 1xFault Relay Outputs |  |
| P-IP66 | Stainless Series IP66 Adapter |  |
| P-GTA | Celling Mount Collecting Cone |  |
| P-ASU | Prosense Sampling Unit, Diffusion Type |  |
| P-NYY12 | Additional Atex Certified 1/2" NPT Cable Gland |  |
| PK-KEP | Calibration Cap |  |
| SP-P-SB01 | Semiconductor Sensor Board |  |
| SP-P-SB03 | Infrared Sensor Board |  |
| SP-P-SB04 | Electrochemical Sensor Board |  |
| SP-P-SB05 | Pellistor Sensor Board |  |
| SP-P-SB06 | PID Sensor Board |  |
| SP-P-SM01-72 | 72 Semiconductor Sensor Module |  |
| SP-P-SM01-90 | 90 Semiconductor Sensor Module |  |
| SP-P-SM01-91 | 91 Semiconductor Sensor Module |  |
| SP-P-SM03-92 | 92 Infrared Sensor Module |  |
| SP-P-SM03-93 | 93 Infrared Sensor Module |  |
| SP-P-SM03-94 | 94 Infrared Sensor Module |  |
| SP-P-SM03-71 | 71 Infrared Sensor Module |  |
| SP-P-SM03-HC | HC LEL Infrared Sensor Module |  |
| SP-P-SM03-CHV | CH4 Vol Infrared Sensor Module |  |
| SP-P-SM05-HC | HC LEL Pellistor Sensor Module |  |
| SP-P-SM05-60 | 60 LEL Pellistor Sensor Module |  |
| SP-P-SM04-36 | 36 Electrochemical Sensor Module |  |
| SP-P-SM04-36B | 36B Electrochemical Sensor Module |  |
| SP-P-SM04-36C | 36C Electrochemical Sensor Module |  |
| SP-P-SM04-44 | 44 Electrochemical Sensor Module |  |
| SP-P-SM04-44B | 44B Electrochemical Sensor Module |  |
| SP-P-SM04-44C | 44C Electrochemical Sensor Module |  |
| SP-P-SM04-44D | 44D Electrochemical Sensor Module |  |
| SP-P-SM04-44E | 44E Electrochemical Sensor Module |  |
| SP-P-SM04-48 | 48 Electrochemical Sensor Module |  |
| SP-P-SM04-48B | 48B Electrochemical Sensor Module |  |
| SP-P-SM04-48C | 48C Electrochemical Sensor Module |  |
| SP-P-SM04-48D | 48D Electrochemical Sensor Module |  |
| SP-P-SM04-48E | 48E Electrochemical Sensor Module |  |
| SP-P-SM04-48F | 48F Electrochemical Sensor Module |  |
| SP-P-SM04-62 | 62 Electrochemical Sensor Module |  |
| SP-P-SM04-62B | 62B Electrochemical Sensor Module |  |
| SP-P-SM04-64 | 64 Electrochemical Sensor Module |  |
| SP-P-SM04-64B | 64B Electrochemical Sensor Module |  |
| SP-P-SM04-64C | 64C Electrochemical Sensor Module |  |
| SP-P-SM04-64D | 64D Electrochemical Sensor Module |  |
| SP-P-SM04-64E | 64E Electrochemical Sensor Module |  |
| SP-P-SM04-64F | 64F Electrochemical Sensor Module |  |
| SP-P-SM04-64G | 64G Electrochemical Sensor Module |  |
| SP-P-SM04-64H | 64H Electrochemical Sensor Module |  |
| SP-P-SM04-64I | 64I Electrochemical Sensor Module |  |
| SP-P-SM04-65 | 65 Electrochemical Sensor Module |  |
| SP-P-SM04-66 | 66 Electrochemical Sensor Module |  |
| SP-P-SM04-66B | 66B Electrochemical Sensor Module |  |
| SP-P-SM04-66C | 66C Electrochemical Sensor Module |  |
| SP-P-SM04-66D | 66D Electrochemical Sensor Module |  |
| SP-P-SM04-67 | 67 Electrochemical Sensor Module |  |
| SP-P-SM04-67B | 67B Electrochemical Sensor Module |  |
| SP-P-SM04-68 | 68 Electrochemical Sensor Module |  |
| SP-P-SM04-69 | 69 Electrochemical Sensor Module |  |
| SP-P-SM04-69B | 69B Electrochemical Sensor Module |  |
| SP-P-SM04-74 | 74 Electrochemical Sensor Module |  |
| SP-P-SM04-75 | 75 Electrochemical Sensor Module |  |
| SP-P-SM04-76 | 76 Electrochemical Sensor Module | |
| SP-P-SM04-79 | 79 Electrochemical Sensor Module |  |
| SP-P-SM04-79B | 79B Electrochemical Sensor Module |  |
| SP-P-SM04-82 | 82 Electrochemical Sensor Module |  |
| SP-P-SM04-82B | 81B Electrochemical Sensor Module |  |
| SP-P-SM04-83 | 83 Electrochemical Sensor Module |  |
| SP-P-SM04-84 | 84 Electrochemical Sensor Module |  |
| SP-P-SM04-86 | 86 Electrochemical Sensor Module |  |
| SP-P-SM04-87 | 87 Electrochemical Sensor Module |  |
| SP-P-SM04-88 | 88 Electrochemical Sensor Module |  |
| SP-P-SM04-89 | 89 Electrochemical Sensor Module |  |
| SP-P-SM04-95 | 95 Electrochemical Sensor Module |  |
| SP-P-SM04-96 | 96 Electrochemical Sensor Module |  |
| SP-P-ST01-72 | 72 Semiconductor Sensor Head |  |
| SP-P-ST01-90 | 90 Semiconductor Sensor Head |  |
| SP-P-ST01-91 | 91 Semiconductor Sensor Head |  |
| SP-P-ST03-92 | 92 Infrared Sensor Head |  |
| SP-P-ST03-93 | 93 Infrared Sensor Head | |
| SP-P-ST03-94 | 94 Infrared Sensor Head |  |
| SP-P-ST03-71 | 71 Infrared Sensor Head |  |
| SP-P-ST03-HC | HC LEL Infrared Sensor Head |  |
| SP-P-ST03-CHV | CH4 Vol Infrared Sensor Head |  |
| SP-P-ST05-HC | HC LEL Pellistor Sensor Head |  |
| SP-P-ST05-60 | 60 LEL Pellistor Sensor Head |  |
| SP-P-ST04-36 | 36 Electrochemical Sensor Head |  |
| SP-P-ST04-36B | 36B Electrochemical Sensor Head |  |
| SP-P-ST04-36C | 36C Electrochemical Sensor Head |  |
| SP-P-ST04-44 | 44 Electrochemical Sensor Head |  |
| SP-P-ST04-44B | 44B Electrochemical Sensor Head |  |
| SP-P-ST04-44C | 44C Electrochemical Sensor Head |  |
| SP-P-ST04-44D | 44D Electrochemical Sensor Head |  |
| SP-P-ST04-44E | 44E Electrochemical Sensor Head |  |
| SP-P-ST04-48 | 48 Electrochemical Sensor Head |  |
| SP-P-ST04-48B | 48B Electrochemical Sensor Head |  |
| SP-P-ST04-48C | 48C Electrochemical Sensor Head |  |
| SP-P-ST04-48D | 48D Electrochemical Sensor Head |  |
| SP-P-ST04-48E | 48E Electrochemical Sensor Head |  |
| SP-P-ST04-48F | 48F Electrochemical Sensor Head |  |
| SP-P-ST04-62 | 62 Electrochemical Sensor Head |  |
| SP-P-ST04-62B | 62B Electrochemical Sensor Head |  |
| SP-P-ST04-64 | 64 Electrochemical Sensor Head |  |
| SP-P-ST04-64B | 64B Electrochemical Sensor Head |  |
| SP-P-ST04-64C | 64C Electrochemical Sensor Head |  |
| SP-P-ST04-64D | 64D Electrochemical Sensor Head | |
| SP-P-ST04-64E | 64E Electrochemical Sensor Head |  |
| SP-P-ST04-64F | 64F Electrochemical Sensor Head |  |
| SP-P-ST04-64G | 64G Electrochemical Sensor Head |  |
| SP-P-ST04-64H | 64H Electrochemical Sensor Head |  |
| SP-P-ST04-64I | 64I Electrochemical Sensor Head |  |
| SP-P-ST04-65 | 65 Electrochemical Sensor Head |  |
| SP-P-ST04-66 | 66 Electrochemical Sensor Head |  |
| SP-P-ST04-66B | 66B Electrochemical Sensor Head |  |
| SP-P-ST04-66C | 66C Electrochemical Sensor Head |  |
| SP-P-ST04-66D | 66C Electrochemical Sensor Head |  |
| SP-P-ST04-67 | 67 Electrochemical Sensor Head |  |
| SP-P-ST04-67B | 67B Electrochemical Sensor Head |  |
| SP-P-ST04-68 | 68 Electrochemical Sensor Head |  |
| SP-P-ST04-69 | 69 Electrochemical Sensor Head |  |
| SP-P-ST04-69B | 69B Electrochemical Sensor Head |  |
| SP-P-ST04-74 | 74 Electrochemical Sensor Head |  |
| SP-P-ST04-75 | 75 Electrochemical Sensor Head |  |
| SP-P-ST04-76 | 76 Electrochemical Sensor Head |  |
| SP-P-ST04-79 | 79 Electrochemical Sensor Head |  |
| SP-P-ST04-79B | 79B Electrochemical Sensor Head |  |
| SP-P-ST04-82 | 82 Electrochemical Sensor Head |  |
| SP-P-ST04-82B | 81B Electrochemical Sensor Head |  |
| SP-P-ST04-83 | 83 Electrochemical Sensor Head | |
| SP-P-ST04-84 | 84 Electrochemical Sensor Head |  |
| SP-P-ST04-86 | 86 Electrochemical Sensor Head |  |
| SP-P-ST04-87 | 87 Electrochemical Sensor Head |  |
| SP-P-ST04-88 | 88 Electrochemical Sensor Head |  |
| SP-P-ST04-89 | 89 Electrochemical Sensor Head | |
| SP-P-ST04-95 | 95 Electrochemical Sensor Head |  |
| SP-P-ST04-96 | 96 Electrochemical Sensor Head |  |
| SP-SH30-SIN | Sinter Set(10pcs) for SH Sensor Head |  |
| SP-P-GB | P Series Enclosure (Excluding Lid) |  |
| SP-P-GB-N | P Series Lid |  |
| SP-P-TB01 | 01 P Series Transmitter |  |
| SP-P-TB03 | 03 P Series Transmitter |  |
| SP-P-TB04 | 04 P Series Transmitter |  |
| SP-P-TB05 | 05 P Series Transmitter |  |
