S-DP32 Gas Control Panel is designed to manage the Prosense combustible, toxic, and oxygen gas detectors via Modbus RS485 trough one cable.
Ask the Expert
• Input: 1 serial input up to 32 detectors and 1 digital(24VDC) input
• Display: Bright and clear LCD display
• Relays: 2 Alarm, 1 Fault and AUX adjustable relay contacts. Up to 24 extra relay outputs for specific applications
• Logging: Stores all alarm, fault and maintenance events up 30logs to provide a history of detectors connected
• Monitoring: Continuously monitoring of detector gas concentrations
• Diversification: Different gases in different measuring units(ppm,LEL,VOL) can be connected
• Body: PC(Polycarbonate) superb performance under harsh environmental conditions with IP66 protection class.
• Visual/Audial: Independent Alarm and Fault LED indicators for each detector and buzzer
• Modular: Modular structure allows the user specific installation and provide efficiency during the maintenance.
| Buzzer | YES |
| Programming | User friendly software enables easy programming with 4 buttons on panel door |
| Power Supply | 220 VAC +/?10% - 110VAC +/-10% |
| LED Indicators | 6 LED indicators for Alarm1, Alarm2, Fault, AUX, Battery and Power LED indicators |
| Monitoring | Simultaneously monitoring measurements, alarm and fault status |
| Dimensions/Weight | 546x276x186mm / 6 KG |
| Relay Outputs | Programmable Fault, Alarm1, Alarm2, AUX contacts Adjustable NO/NC contacts Optional Alarm1, Alarm2, and fault relays for each detector |
| Power Consumption | 27VDC/250mA?8,4W max. without connected detectors |
| Display | Graphic LCD 128x64 |
| Event Logging | Storages Alarm, Fault and maintenance logs up to 24 event |
| Input | 1 Serial Input to communicate up to 32 detectors and 1 Digital Input |
| Main Power Fuse | 2A |
| Backup Battery | 2x12V 7A/h (Optional) |
| Backup Battery Fuse | 2A |
| Mounting | Modular Structure |
| S-8RA1 | 8 Integrated Relay Modules for Alarm 1 |  |
| S-KEY | Panel Lock to prevent unauthorized access |  |
| SP-DP32-TBK | S-DP32 Panel Board, Including Lid and RS485 Board |  |
| SP-DP32-RS | S-DP32 RS485 Board |  |
| SP-DPX32-TBK | S-DPX032 Panel Board, Including Lid and RS485 Board |  |
